I recently changed hosting providers, and as a result had to rebuild a bunch of the infrastructure that hosts this site. While going through this process, I ran into an interesting security issue, and I thought I’d document while it was fresh in my mind.
When first setting up the server I went through a few simple steps to increase its security and decrease the potential attack footprint (the cool kids call this process “hardening”). These steps included:
I then went on to install Portainer, which is a nice web-based GUI for managing Docker containers that I had used in the past. It’s not “enterprise-ready” like some other solutions out there, but it’s quite simple and good enough for my use case.
I used Portainer’s
docker-compose-like syntax to set up a bunch of services
on the machine, including the web server for this site. I then opened my
browser to test this site out, and lo and behold, everything worked great on
the first try!
Wait a second.
It took me a few minutes but I realized that I shouldn’t be able to access the web site, since I had explicily set up UFW before to only allow SSH connections. I double checked my UFW configuration:
colin@fajita:~$ sudo ufw status verbose Status: active Logging: on (low) Default: deny (incoming), allow (outgoing), deny (routed) New profiles: skip To Action From -- ------ ---- 22/tcp ALLOW IN Anywhere 22/tcp (v6) ALLOW IN Anywhere (v6) colin@fajita:~$
Default deny on incoming connections, and only port 22 is open. Yet, I can still access my site which is running on port 443. What gives?
After doing some research, I discovered that by default, Docker adds rules to
iptables (the actual kernel-level firewall that UFW wraps) in a way that
bypasses the rules that UFW sets up for you. Ugh.
The best solution I found was provided in the ufw-docker GitHub repo.
You add a short set of iptables commands to the
/etc/ufw/after.rules file and
then you’re set. Once I implemented these changes, I could no longer connect to
the website, as I expected. To allow incoming connections, I had to use this
(slightly longer than normal) UFW command:
ufw route allow proto tcp from any to any port 80
It turns out that with this workaround, you need to use the slightly longer
ufw route allow syntax any time you want to open a port that is mapped to a
Docker container. This is not a horrible inconvenience for me, as I have a single
reverse proxy running on ports 80 and 443 that forwards connections to all of the
websites that I host on this machine, so I only needed to open those ports once.
I hope this helps someone out there!
